Vehicle Contol Unit

EKE-Trainnet® Vehicle Control Unit can connect with sub-systems and the Train Communication Network, providing advanced control and diagnostic functions. Our modular design and customisation provide tailored solutions, while our integration expertise and advanced diagnostics ensure exceptional performance and reliability. The EKE-Trainnet® Vehicle Control Unit can be certified to SIL 2.

badge
COMPLIANCE:
EN 50155, EN 45545
Technical Specification for Vehicle Control Units

Build a Vehicle Control Unit using the following modules

EKE-Trainnet® Vehicle Control Units can control any train sub-system, such as brakes or doors. It can be used for both physical control and diagnostics of train sub-systems. The following modules are required to create the Vehicle Control Unit. Click on an image to explore related content.

Modular Concept

All our EKE-Trainnet® products are modular, enabling you to precisely select the modules you require. Modules can be combined for a very flexible and versatile solution. The modular design enables you to select only the features you need for a cost efficient solution. It also means repairs and upgrades are quick and easy.

Below is an example of a Vehicle Control Unit made up of a selection of common modules. Hover over each area to view a brief description or click to access the full module page.

1

Digital Input Output Module (DIO)

Receives digital signals through its input channels and delivers them to the train computer’s Central Processing Unit (CPU) module for processing.

2

Pt100/Pt1000 Temperature Sensor Input Module (PTI)

Used to acquire the signals from the Pt100 (PTI2037) or Pt1000 (PTI3593) temperature sensors (resistance measurement) and convert them into temperature values expressed in degrees Celsius.

3

Analogue Input Module (AIM)

Converts analogue signals and makes them available to the train computer’s CPU module.

4

CPU with Serial Links (CPS)

A central processing unit providing serial communication interfaces.

5

Multifunction Vehicle Bus Interface Module (MVB)

Used to create vehicle buses or train communication networks.

6

Power Supply Unit for VME (PSV)

A power supply unit required to power the vehicle control unit.

7

Vehicle Identification Unit (VIU)

Provides an interface for the Electronic Serial Number (ESN) for device identification and configuration.

Build Your Own Applications

EKE-Trainnet® Vehicle Control Unit is built on an open-source Linux platform powered by CODESYS®. It allows you to develop custom applications.

If you prefer to develop in-house. EKE-Electronics provides training, tools, and guidance to support your development efforts. Alternatively, EKE-Electronics has expertise to develop fully or partially software on your behalf.

Typical applications for the Vehicle Control Unit include:
Diagnostics
SIL and Safety Application
CCTV System Management
PIS/PA System Management
HVAC Management
Tank Level Monitoring
Crew HMI Management
Door Management
Battery Charge Monitoring
Brakes and Traction Management
Lighting Management
Train to Wayside Communication Management
Why Choose EKE-Electronics for Vehicle Control Units?

The EKE-Trainnet® Vehicle Control Unit (VCU) is a robust and adaptable system based on an open-source Linux platform. It supports the development of safety applications up to SIL 2. The modular design allows for customisation to meet specific requirements, while its open architecture facilitates the integration of third-party hardware and software. Advanced diagnostics and system monitoring enhance reliability and performance.

Modular design and customisation

Our EKE-Trainnet® VCUs are built by selecting the most suitable modules from our EKE-Trainnet® range to meet your requirements. The open-source platform provides different approaches for customisation and integration.

Advanced control and diagnostics

Controlling various train subsystems such as brakes and doors, the EKE-Trainnet® VCU manages both physical functions and diagnostics. These applications can run on the same train computers used for TCN Gateway functions, providing a compact and cost-effective solution.

Supports a range of interfaces

EKE-Trainnet® VCU supports a range of bus technologies, including WTB, MVB, CAN, Serial Links, and Ethernet. Flexible connectivity options are enhanced by a wide array of Input/Output Modules.

Download Brochures
EKE-Trainnet® Train Control and Management Systems
EKE-Trainnet® Technical Specifications
Find out how we can work together

Technical Specification for Vehicle Control Unit

Dimensions (W x H x D):

3U 44TE Rack

280 mm x 133 mm x 215 mm (installation width 240 mm)

3U 84TE Rack

483 mm x 133 mm x 215 mm (installation width 443 mm)

6U 84TE Rack

483 mm x 266 mm x 215 mm (installation width 443 mm)

Weight:

Depends on rack and installed modules

Input Power:

24, 36, 48, 52, 72 or 110 V DC

Temperature Range (operational):

-40 °C…+70 °C

MTBF (40 ºC ambient temperature):

Depends on installed modules

Interface options:
  • WTB,
  • MVB,
  • CAN,
  • Ethernet,
  • Serial Links,
  • Analogue Input Module,
  • High Speed Analogue Input Module,
  • Digital Input/Output Module,
  • Digital Relay Output Module,
  • Analogue Output Module,
  • PT100/PT1000 Temperature Sensor Input Module.
